200 Nm ~ 50μM Diameter Nano Bubble Generator For Sewage Treatment Plant 220 Volt

China 200 Nm ~ 50μM Diameter Nano Bubble Generator For Sewage Treatment Plant 220 Volt supplier
200 Nm ~ 50μM Diameter Nano Bubble Generator For Sewage Treatment Plant 220 Volt supplier 200 Nm ~ 50μM Diameter Nano Bubble Generator For Sewage Treatment Plant 220 Volt supplier

Large Image :  200 Nm ~ 50μM Diameter Nano Bubble Generator For Sewage Treatment Plant 220 Volt

Product Details:

Place of Origin: China
Brand Name: HOLLY
Model Number: HLYZ

Payment & Shipping Terms:

Minimum Order Quantity: 1Set
Price: USD 1500-6700
Packaging Details: Wooden package
Delivery Time: 20 days after payment
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Contact Now
Detailed Product Description
Product Name: Nano Bubble Generator Material: Stainless Steel Or Spraying Coating Steel
Application: Fishing Farming,wastewate Treatment Bubble Size: 80nm - 20μm
Voltage(V): 220 Power(KW): 3

Ozone Micro Bubble Generator Aerator For Sewage Treatment Plant

Feature of product

1. Generate high density Bubble Micro to surround the object to be cleaned.

2. Micro Bubble formation charged (negatively charged) state, selective adsorption the dirt

(positive), will sucked on bubble surface.

3. Micro Bubble stripping and cleaning(float separation out dirt), achieve cleaning and

 sterilizing effect.

4. High density air bubble group to drive the mixing tank of the object, to promote the effect of

washing.

5. Micro Bubble bring water contact with an object, the bubble'pressure caused by the

destruction of the impact of the dirt away.

Introduction

A micro-nanobubble technology has attracted much interest in bio-related areas such as

bioremediation, aquaculture and plant cultivation. MNBs are superior to macro-bubbles

because they have larger interfacial area, higher inner pressure, lower rising velocity in water,

long lifetime and high mass transfer efficiency. Also, the generation method of MNBs has an

impact on their properties. All these factors will dramatically improve dissolved oxygen supply.

Advantage

1. Using high-pressure rotary flow transient release technology,high density of micro nano

bubble,non-clogging,easy to maintain.

2. Functional bubble diameter of 200 nm ~ 50μm , saturated water can be quickly produced

with good gas-liquid dissolving effect.

3. Stable performance, high efficiency, low noise.

4. Wide range of application,such as : waste water /gas treatment aquaculture,agricultural

irrigation,bath and so on.

Technical Parameters


 HLYZ-001HLYZ-002HLYZ-006HLYZ-012
Water Inflow(m3/h)12612
Voltage(V)220/380220/380380380
Power(KW)0.51.136
Size(mm)660*530*800660*530*800850*550*850860*560*850
Working Environment(ºC)0-100ºC0-100ºC0-100ºC0-100ºC
Working Capacity( cubic water)9030012002200
Bubble Diameter(nm-μm)80nm-20μm80nm-20μm80nm-20μm80nm-20μm
Gas-liquid Mixing Proportion1:8-1:121:8-1:121:8-1:121:8-1:12
Gas-liquid Dissolving Rate>95%>95%>95%>95%





200 Nm ~ 50μM Diameter Nano Bubble Generator For Sewage Treatment Plant 220 Volt
